Trójfazowy falownik hybrydowy 3-15 kW
Opis

The Afore AF series three phase storage inverters are designed to increase energy independence for homeowners and commercial users. The power range is from 3.0kW to 15kW, compatible with high voltage (80-600V) batteries.

Support for Time-of-use Optimization

AFCI (Optional) & Rapid Shutdown Ready

Build in Anti-feed-in Function

100% unbalanced output

Product introduction

Technical DataAF3K-MTHAF4K-MTHAF5K-MTHAF6K-MTHAF8K-MTHAF10K-MTH AF12K-MTHAF15K-MTH
PV Input
Max. DC Input Power (kW)567.5912151822.5
Max. PV Voltage (V)10001000100010001000100010001000
Rated DC Input Voltage (V)620620620620620620620620
DC Input Voltage Range (V)150-1000150-1000150-1000150-1000150-1000150-1000150-1000150-1000
MPPT Voltage Range (V)150- 850150-850150- 851150-851150- 852150-852150- 853150-853
Full MPPT Range(V)200-850200-850200-850250-850300-850500-850500-850500-850
Start-up Voltage (V)160160160160160160160160
Max. DCInput Current (A)18.5x218.5x218.5x218.5x218.5x218.5x218.5x218.5x2
Max. Short Current(A)25x225x225x225x225x225x225x225x2
No. of MPPT Tracker / Strings2/22/22/22/22/22/22/22/2
Battery Port
Battery Nominal Voltage (V)350350350350350350450500
Battery Voltage Range (V)80-60080-60080-60080-60080-60080-60080-60080-600
Max. Charge/Discharge Current (A)3030303030303030
Max.Charge/Discharge Power (kW)34568101215
Charging Curve3 Stages3 Stages3 Stages3 Stages3 Stages3 Stages3 Stages3 Stages
Compatible Battery TypeLi-ion/Lead-acid / Sodium metal chloride batteryLi-ion/Lead-acid/ Sodium metal chloride batteryLi-ion/Lead-acid / Sodium metal chloride batteryLi-ion/Lead-acid/ Sodium metal chloride batteryLi-ion/Lead-acid / Sodium metal chloride batteryLi-ion/Lead-acid/ Sodium metal chloride batteryLi-ion/Lead-acid / Sodium metal chloride batteryLi-ion/Lead-acid/ Sodium metal chloride battery
AC Grid
Nominal AC Output Power (kW)34568101215
Max.AC Input/Output Power (kVA)4.5/3.36/4.47.5/5.59/6.612/8.815/1118/13.222.5/16.5
Max. AC Output Current (A)5.378.510.513.51721.527
Nominal AC Voltage (V)3P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/400
Nominal AC Frenquency (Hz)50/6050/6050/6050/6050/6050/6050/6050/60
Power Factor1 (-0.8-0.8 adjustable)1 (-0.8-0.8 adjustable)1 (-0.8-0.8 adjustable)1 (-0.8-0.8 adjustable)1 (-0.8-0.8 adjustable)1 (-0.8-0.8 adjustable)1 (-0.8-0.8 adjustable)1 (-0.8-0.8 adjustable)
Current THD (%)<3%<3%<3%<3%<3%<3%<3%<3%
AC Load Output (Back-up)
Nominal Output Power (VA)30004000500060008000100001200015000
Nominal Output Voltage (V)3P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/4003P+N+PE/3P+PE 230/400
Nominal Output Frequency (Hz)50/6050/6050/6050/6050/6050/6050/6050/60
Nominal Output Current (A)4.45.87.38.711.614.517.421.8
Peak Output Power3300VA, 60s4400VA,60s5500VA, 60s6600VA, 60s8800VA,60s11000VA,60s 13200VA, 60s16500VA, 60s
THDV (with linear load)<3%<3%<3%<3%<3%<3%<3%<3%
Switching Time (ms)<10<10<10<10<10<10<10<10
Efficiency
Europe Efficiency97.50%97.50%97.50%97.50%97.50%97.50%97.50%97.50%
Max. Efficiency98.00%98.00%98.00%98.00%98.20%98.20%98.30%98.30%
Battery Charge/Discharge Efficiency98%98%98%98%98.00%98.00%98.00%98.00%
Protection
Reverse Polarity ProtectionYesYesYesYesYesYesYesYes
Over Current/Voltage ProtectionYesYesYesYesYesYesYesYes
Anti-islanding ProtectionYesYesYesYesYesYesYesYes
AC Short-ciruit ProtectionYesYesYesYesYesYesYesYes
Leakage Current DetectionYesYesYesYesYesYesYesYes
Ground Fault MonitoringYesYesYesYesYesYesYesYes
Grid MonitoringYesYesYesYesYesYesYesYes
Enclosure Protect LevelIP66IP66IP66IP66IP66IP66IP66IP66
AC/DC surge protectiontype lltype lltype lltype lltype lltype lltype lltype ll
General Data
Dimensions(WxHxD,mm)370x598.5x192mm370x598.5x192mm370x598.5x192mm370x598.5x192mm370x598.5x192mm370x598.5x192mm370x598.5x192mm370x598.5x192mm
Weight (kg)22kg22kg22kg22kg22kg22kg22kg22kg
TopologyTransformerlessTransformerlessTransformerlessTransformerlessTransformerlessTransformerlessTransformerlessTransformerless
Cooling ConceptNatural ConvectionNatural ConvectionNatural ConvectionNatural ConvectionIntelligent FanIntelligent FanIntelligent FanIntelligent Fan
Relatively Humidity0-100%0-100%0-100%0-100%0-100%0-100%0-100%0-100%
Operating Temperature Range (℃)-25 to 60℃-25 to 60℃-25 to 60℃-25 to 60℃-25 to 60℃-25 to 60℃-25 to 60℃-25 to 60℃
Operating Altitude (m)<4000<4000<4000<4000<4000<4000<4000<4000
Standby Consumption (W)<5<5<5<5<5<5<5<5
Display & Communication InterfacesLCD, LED, RS485, CAN, Wi-Fi, GPRS,4GLCD, LED, RS485, CAN, Wi-Fi, GPRS,4GLCD, LED, RS485, CAN, Wi-Fi, GPRS,4GLCD, LED, RS485, CAN, Wi-Fi, GPRS,4GLCD,LED, RS485, CAN, Wi-Fi GPRS, 4GLCD,LED, RS485, CAN, Wi-Fi GPRS, 4GLCD,LED, RS485, CAN, Wi-Fi GPRS, 4GLCD,LED, RS485, CAN, Wi-Fi GPRS, 4G
Certification & ApprovalsNRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2
EMCEN61000-6-2 EN61000-6-3EN61000-6-2 EN61000-6-3EN61000-6-2 EN61000-6-3EN61000-6-2 EN61000-6-3EN61000-6-2,EN61000-6-3EN61000-6-2,EN61000-6-3EN61000-6-2,EN61000-6-3EN61000-6-2,EN61000-6-3
