Jednofazowy falownik sprzężony z prądem przemiennym

AF1-6K-SL-0

Download PDF >

 Contact US >

Jednofazowy falownik sprzężony z prądem przemiennym
Opis

Afore AC Coupled Inverter (1kW-6kW) suitable for both single-phase & three-phase systems. It can be fitted alongside string inverter, enabling you to upgrade to solar battery storage system without changing your current installation.

97.6% Charge and Discharge Efficiency

Integrated WlFl Monitoring & Remote Parameter

Plug & Play, Easy Maintenance

IP65 Water-resistant & Dustproof

Product introduction

Technical DataAF1K-SL-0AF1.5K-SL-0AF2K-SL-0AF2.5K-SL-0AF3K-SL-0
Battery Port
Max Charge/Discharge Power (KW)11.522.53
. Max.Charge/Discharge Current (A)2540506380
Battery Normal Voltage (V)51.251.251.251.251.2
Battery Voltage Range (V)40-6040-6040-6040-6040-60
Battery TypeLi-ion/lead-acid etc.Li-ion/lead-acid etc.Li-ion/lead-acid etc.Li-ion/lead-acid etc.Li-ion/lead-acid etc.
AC Grid
Max Continuous Current (A)57101214
Max Continuous Power (kVA)11.522.53
Nominal Grid Current(A)4.6/4.46.9/6.69.1/8.711.4/10.913.7/13.1
Nominal Grid Voltage (V)198 to 242 @220 / 207 to 253 @ 230198 to 242 @220 / 207 to 253 @ 230198 to 242 @220 / 207 to 253 @ 230198 to 242 @220 / 207 to 253 @ 230198 to 242 @220 / 207 to 253 @ 230
Nominal Grid Frequency (Hz)50/6050/6050/6050/6050/60
Power Factor0.999 (Adjustable from 0.8 overexcited to 0.8 underexcited)0.999 (Adjustable from 0.8 overexcited to 0.8 underexcited)0.999 (Adjustable from 0.8 overexcited to 0.8 underexcited)0.999 (Adjustable from 0.8 overexcited to 0.8 underexcited)0.999 (Adjustable from 0.8 overexcited to 0.8 underexcited)
Current THD (%)<3<3<3<3<3
AC Load Output
Max Continuous Current (A)57101214
Max Continuous Power (kVA)11.522.53
Max Peak Current (A) (10min)6.9/6.610.5/10.013.7/13.117.1/16.420.5/19.6
Max Peak Power (kVA) (10min)1.52.333.754.5
Nominal AC Voltage L-N (V)220/230220/230220/230220/230220/230
Nominal AC Frequency (Hz)50/6050/6050/6050/6050/60
Switching Time (ms)SeamlessSeamlessSeamlessSeamlessSeamless
Voltage THD (%)<3<3<3<3<3
Efficiency
Max. Efficiency(%)97.697.697.697.697.6
Bat. between AC Efficiency (%)96.896.896.896.896.8
Protection
Over Current/Voltage ProtectionYesYesYesYesYes
Anti-Islanding ProtectionYesYesYesYesYes
AC Short Circuit ProtectionYesYesYesYesYes
Residual Current DetectionYes Yes Yes Yes Yes
Ground Fault MonitoringYesYesYesYesYes
Insulation Resister DetectionYesYesYesYesYes
Enclosure Protect LevelIP65 /NEMA4XIP65 /NEMA4XIP65 /NEMA4XIP65 /NEMA4XIP65 /NEMA4X
General Data
Dimensions (WxHxD,mm)370x535x192370x535x192370x535x192370x535x192370x535x192
Weight18.518.518.518.518.5
TopologyTranformerlessTranformerlessTranformerlessTranformerlessTranformerless
Cooling1 : Fan1 : Fan1 : Fan1 : Fan1 : Fan
Relative Humidity0-100%0-100%0-100%0-100%0-100%
Operating Temperature Range (℃)25 to 6025 to 6025 to 6025 to 6025 to 60
Operating Altitude (m)<4000<4000<4000<4000<4000
Standby Consumption (W)<10<10<10<10<10
MountingWall BracketWall BracketWall BracketWall BracketWall Bracket
Communication with RSDSUNSPECSUNSPECSUNSPECSUNSPECSUNSPEC
Display & Communication InterfacesLCD, LED, RS485, CAN, Wi-Fi, GPRS, 4GLCD, LED, RS485, CAN, Wi-Fi, GPRS, 4GLCD, LED, RS485, CAN, Wi-Fi, GPRS, 4GLCD, LED, RS485, CAN, Wi-Fi, GPRS, 4GLCD, LED, RS485, CAN, Wi-Fi, GPRS, 4G
Certification & ApprovalsNRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2
EMCEN61000-6-2, EN61000-6-3EN61000-6-2, EN61000-6-3EN61000-6-2, EN61000-6-3EN61000-6-2, EN61000-6-3EN61000-6-2, EN61000-6-3
Technical DataAF3.6K-SL-0AF4K-SL-0AF4.6K-SL-0AF5K-SL-0AF5.5K-SL-0AF6K-SL-0
Battery Port
Max.Charge/Discharge Power (kW)3.644.655.56
Max. Charge/Discharge Current (A)80120120120120120
Battery Normal Voltage (V)51.251.251.251.251.251.2
Battery Voltage Range (V)40-6040-6040-6040-6040-6040-60
Battery TypeLi-ion/lead-acid etc.Li-ion/lead-acid etc.Li-ion/lead-acid etc.Li-ion/lead-acid etc.Li-ion/lead-acid etc.Li-ion/lead-acid etc.
AC Grid
Max Continuous Current (A)171922232628
Max Continuous Power (kVA)3.644.655.56
Nominal Grid Current (A)16.4/15.718.2/17.421.0/20.022.8/21.825.0/24.027.3/26.1
Nominal Grid Voltage (V)198 to 242@220 / 207 to 253 @ 230198 to 242@220 / 207 to 253 @ 230198 to 242@220 / 207 to 253 @ 230198 to 242@220 / 207 to 253 @ 230198 to 242@220 / 207 to 253 @ 230198 to 242@220 / 207 to 253 @ 230
Nominal Grid Frequency (Hz)50/6050/6050/6050/6050/6050/60
Power Factor0.999 (Adjustable from 0.8 overexcited to 0.8 underexcited)0.999 (Adjustable from 0.8 overexcited to 0.8 underexcited)0.999 (Adjustable from 0.8 overexcited to 0.8 underexcited)0.999 (Adjustable from 0.8 overexcited to 0.8 underexcited)0.999 (Adjustable from 0.8 overexcited to 0.8 underexcited)0.999 (Adjustable from 0.8 overexcited to 0.8 underexcited)
Current THD (%)<3<3<3<3<3<3
AC Load Output
Max Continuous Current (A)171922232628
Max Continuous Power (kVA)3.644.655.56
Max Peak Current (A) (10min)24.6/23.527.3/26.131.4/30.0 34.1/32.737.8/36.141.0/39.2
Max Peak Power (kVA) (10min)5.466.97.58.39
Nominal AC Voltage L-N (V)220/230220/230220/230220/230220/230220/230
Nominal AC Frequency (Hz)50/6050/6050/6050/6050/6050/60
Switching Time (s)SeamlessSeamlessSeamlessSeamlessSeamlessSeamless
Voltage THD (%)<3<3<3<3<3<3
Efficiency
Max. Efficiency(%)97.697.697.697.697.697.6
Bat. between AC Efficiency (%)96.896.896.896.896.896.8
Protection
Over Current/Voltage ProtectionYesYesYesYesYesYes
Anti-Islanding ProtectionYesYesYesYesYesYes
AC Short Circuit ProtectionYesYesYesYesYesYes
Residual Current DetectionYesYesYesYesYesYes
Ground Fault MonitoringYesYesYesYesYesYes
Insulation Resister DetectionYesYesYesYesYesYes
Enclosure Protect LevelIP65 /NEMA4XIP65 /NEMA4XIP65 /NEMA4XIP65 /NEMA4XIP65 /NEMA4XIP65 /NEMA4X
General Data
Dimensions (Wx H x D,mm)370x535x192370x535x192370x535x192370x535x192370x535x192370x535x192
Weight18.518.520.520.520.520.5
TopologyTranformerlessTranformerlessTranformerlessTranformerlessTranformerlessTranformerless
CoolingIntelligent FanIntelligent FanIntelligent FanIntelligent FanIntelligent FanIntelligent Fan
Relative Humidity Operating Temperature 0-100%0-100%0-100%0-100%0-100%0-100%
Operating Temperature Range (℃)25 to 6025 to 6025 to 6025 to 6025 to 6025 to 60
Operating Altitude (m)<4000<4000<4000<4000<4000<4000
Standby Consumption (W)<10<10<10<10<10<10
MountingWall BracketWall BracketWall BracketWall BracketWall BracketWall Bracket
Communication with RSDSUNSPECSUNSPECSUNSPECSUNSPECSUNSPECSUNSPEC
Display & Communication InterfacesLCD, LED, RS485, CAN, Wi-Fi, GPRS, 4GLCD, LED, RS485, CAN, Wi-Fi, GPRS, 4GLCD, LED, RS485, CAN, Wi-Fi, GPRS, 4GLCD, LED, RS485, CAN, Wi-Fi, GPRS, 4GLCD, LED, RS485, CAN, Wi-Fi, GPRS, 4GLCD, LED, RS485, CAN, Wi-Fi, GPRS, 4G
Certification & ApprovalsNRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2NRS097, G98/G99, EN50549-1, C10/C11, AS4777.2, VDE-AR-N4105, VDE0126, IEC62109-1, IEC62109-2
EMCEN61000-6-2, EN61000-6-3EN61000-6-2, EN61000-6-3EN61000-6-2, EN61000-6-3EN61000-6-2, EN61000-6-3EN61000-6-2, EN61000-6-3EN61000-6-2, EN61000-6-3
