Opis
Jednofazowe falowniki Afore serii HNS są przeznaczone do zastosowań w domowych systemach fotowoltaicznych o mocy od 3 kW do 6 kW. Wszystkie modele posiadają aluminiową obudowę typu unibody, która jest anodyzowana, co zwiększa trwałość i skutecznie zapobiega korozji. Wyposażone w zewnętrzne cewki indukcyjne, obudowy unibody mogą zapewnić wydajne rozpraszanie ciepła, co znacznie poprawia niezawodność i wydłuża żywotność falowników.
Menu falownika jest aktywowane za pomocą przycisków dotykowych. Komunikacja odbywa się za pośrednictwem modułu Wi-Fi (można zmienić na Ethernet / GPRS). Status systemu można sprawdzić w dowolnym miejscu i czasie za pośrednictwem portalu internetowego lub aplikacji.
Sprawność MPPT > 99,9%
Wiele inteligentnych zabezpieczeń
Kompatybilność z modułami bifacial
Monitorowanie poziomu łańcucha
Wprowadzenie produktu
| Technical Data | HNS3000TL | HNS3600TL | HNS4000TL | HNS4950TL*1 | HNS5000TL | HNS6000TL |
|---|---|---|---|---|---|---|
| PV Input Data | ||||||
| Max.DC Power(W) | 4500 | 5400 | 6000 | 7000 | 7000 | 8400 |
| Max.DC Voltage(V) | 600 | 600 | 600 | 600 | 600 | 600 |
| MPPT Voltage Range (V) | 70-550 | 70-550 | 70-550 | 70-550 | 70-550 | 70-550 |
| MPPT Full Power Voltage Range ( tage Range(V) | 110-550 | 130-550 | 145-550 | 180-550 | 180-550 | 220-550 |
| Rated Input Voltage(V) | 360 | 360 | 360 | 360 | 360 | 360 |
| Start-up Voltage (V) | 70 | 70 | 70 | 70 | 70 | 70 |
| Max.Input Current(A) | 14x2 | 14x2 | 14x2 | 14x2 | 14x2 | 14x2 |
| Max.Short Current(A) | 18x2 | 18x2 | 18x2 | 18x2 | 18x2 | 18x2 |
| No.of MPP Tracker/No.of PV String | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 | 2/2 |
| Input Connector Type | MC4 | MC4 | MC4 | MC4 | MC4 | MC4 |
| AC Output Data | ||||||
| Max.Output Power (VA) | 3300*2 | 3960*2 | 4400*2 | 4950 | 5500*2 | 6600*2 |
| Nominal Output Power(W) | 3000 | 3600 | 4000 | 4950 | 5000 | 6000 |
| Max.Output Current (A) | 15 | 17.5 | 20 | 24 | 24 | 28.7 |
| Nominal Output Voltage(V) | L/N/PE,220Vac,230Vac,24OVac | L/N/PE,220Vac,230Vac,24OVac | L/N/PE,220Vac,230Vac,24OVac | L/N/PE,220Vac,230Vac,24OVac | L/N/PE,220Vac,230Vac,24OVac | L/N/PE,220Vac,230Vac,24OVac |
| Grid Voltage Range | 180Vac-276Vac(According to local standard) | 180Vac-276Vac(According to local standard) | 180Vac-276Vac(According to local standard) | 180Vac-276Vac(According to local standard) | 180Vac-276Vac(According to local standard) | 180Vac-276Vac(According to local standard) |
| Nominal Output Frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Grid Frequency Range | 45-55Hz/54-66Hz(According to local standard) | 45-55Hz/54-66Hz(According to local standard) | 45-55Hz/54-66Hz(According to local standard) | 45-55Hz/54-66Hz(According to local standard) | 45-55Hz/54-66Hz(According to local standard) | 45-55Hz/54-66Hz(According to local standard) |
| Output Power Factor | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) |
| Output Current THD | <3% | <3% | <3% | <3% | <3% | <3% |
| Efficiency | ||||||
| Max.Efficiency | 98.20% | 98.20% | 98.20% | 98.20% | 98.20% | 98.20% |
| Euro Efficiency | 97.80% | 97.82% | 97.85% | 97.90% | 97.90% | 97.92% |
| Protection | ||||||
| PV Reverse Polarity Protection | YES | YES | YES | YES | YES | YES |
| PV Insulation Resistance Detection | YES | YES | YES | YES | YES | YES |
| AC Short Circuit Protection | YES | YES | YES | YES | YES | YES |
| AC Over Current Protection | YES | YES | YES | YES | YES | YES |
| AC Over Voltage Protection | YES | YES | YES | YES | YES | YES |
| Anti-Islanding Protection | YES | YES | YES | YES | YES | YES |
| Residual Current Detection | YES | YES | YES | YES | YES | YES |
| Over Temperature Protection | YES | YES | YES | YES | YES | YES |
| Integrated DC switch | YES | YES | YES | YES | YES | YES |
| Surge Protection | Integrated(Type Ill) | Integrated(Type Ill) | Integrated(Type Ill) | Integrated(Type Ill) | Integrated(Type Ill) | Integrated(Type Ill) |
| Smart IV Curve Scaning | YES | YES | YES | YES | YES | YES |
| Quick Arc Fault Circuit interruption | Optional | Optional | Optional | Optional | Optional | Optional |
| General Data | ||||||
| Dimensions(WxHx D,mm) | 358x360x142 | 358x360x142 | 358x360x142 | 358x360x142 | 358x360x142 | 358x360x142 |
| Weight(kg) | 10 | 10 | 10 | 10 | 10 | 10 |
| Protection Degree | IP65 | IP65 | IP65 | IP65 | IP65 | IP65 |
| Enclosure Material | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum |
| Ambient Temperature Range(℃) | -25 to 60 | -25 to 60 | -25 to 60 | -25 to 60 | -25 to 60 | -25 to 60 |
| Humidity Range | 0-100% | 0-100% | 0-100% | 0-100% | 0-100% | 0-100% |
| Topology | Transformerless | Transformerless | Transformerless | Transformerless | Transformerless | Transformerless |
| Communication Interface | RS485/WiFi/Wire Ethernet/GPRS (optional) | RS485/WiFi/Wire Ethernet/GPRS (optional) | RS485/WiFi/Wire Ethernet/GPRS (optional) | RS485/WiFi/Wire Ethernet/GPRS (optional) | RS485/WiFi/Wire Ethernet/GPRS (optional) | RS485/WiFi/Wire Ethernet/GPRS (optional) |
| Cooling Concept | Convection | Convection | Convection | Convection | Convection | Convection |
| Night Power Consumption(W) | <1 | <1 | <1 | <1 | <1 | <1 |
| Max.Operation Altitude(m) | 4000 | 4000 | 4000 | 4000 | 4000 | 4000 |
| Certifications and Standards | ||||||
| EMC Standard | EN/IEC 61000-6-2,EN/IEC 61000-6-3,EN61000-3-2,EN61000-3-3,EN61000-3-11,EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3,EN61000-3-2,EN61000-3-3,EN61000-3-11,EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3,EN61000-3-2,EN61000-3-3,EN61000-3-11,EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3,EN61000-3-2,EN61000-3-3,EN61000-3-11,EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3,EN61000-3-2,EN61000-3-3,EN61000-3-11,EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3,EN61000-3-2,EN61000-3-3,EN61000-3-11,EN61000-3-12 |
| Safety Standard | IEC 60068, UL1741,EN62109 | IEC 60068, UL1741,EN62109 | IEC 60068, UL1741,EN62109 | IEC 60068, UL1741,EN62109 | IEC 60068, UL1741,EN62109 | IEC 60068, UL1741,EN62109 |
| Grid-connection | EEE1547,CSA C22,EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | EEE1547,CSA C22,EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | EEE1547,CSA C22,EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | EEE1547,CSA C22,EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | EEE1547,CSA C22,EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | EEE1547,CSA C22,EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 |
