Opis
Jednofazowe falowniki Afore serii HNS są przeznaczone do zastosowań w domowych systemach fotowoltaicznych o mocy od 1 kW do 3 kW. Wszystkie modele posiadają aluminiową obudowę typu unibody, która jest anodyzowana, co zwiększa trwałość i skutecznie zapobiega korozji. Obudowa unibody zapewnia wydajne odprowadzanie ciepła, co znacznie poprawia niezawodność i wydłuża żywotność falowników.
Menu falownika jest aktywowane za pomocą przycisków dotykowych. Komunikacja odbywa się za pośrednictwem modułu Wi-Fi (można zmienić na Ethernet / GPRS). Status systemu można sprawdzić w dowolnym miejscu i czasie za pośrednictwem portalu internetowego lub aplikacji.
Szybkie przerwanie obwodu łuku elektrycznego (opcjonalnie)
Wiele inteligentnych zabezpieczeń
Kompatybilność z modułami bifacial
Monitorowanie poziomu łańcucha
Wprowadzenie produktu
| Technical Data | HNS1000TL-1 | HNS1500TL-1 | HNS2000TL-1 | HNS2500TL-1 | HNS3000TL-1 |
|---|---|---|---|---|---|
| PV Input Data | |||||
| Max.DC Power(W) | 1500 | 2250 | 3000 | 3750 | 4200 |
| Max.DC Voltage(V) | 500 | 500 | 500 | 500 | 500 |
| MPPT Voltage Range(V) | 50-500 | 50-500 | 50-500 | 50-500 | 50-500 |
| MPPT Full Power Voltage Range(V) | 70-500 | 110-500 | 145-500 | 180-500 | 220-500 |
| Rated Input Voltage(V) | 360 | 360 | 360 | 360 | 360 |
| Start-up Voltage(V) | 50 | 50 | 50 | 50 | 50 |
| Max.Input Current(A) | 14 | 14 | 14 | 14 | 14 |
| Max.Short Current(A) | 18 | 18 | 18 | 18 | 18 |
| No.of MPP Tracker/No.of PV String | 1/1 | 1/1 | 1/1 | 1/1 | 1/1 |
| Input Connector Type | MC4 | MC4 | MC4 | MC4 | MC4 |
| AC Output Data | |||||
| Max.Output Power (VA) | 1100*2 | 1650*2 | 2200*2 | 2750*2 | 3300*2 |
| Nominal Output Power (W) | 1000 | 1500 | 2000 | 2500 | 3000 |
| Max.Output Current(A) | 6 | 9 | 12 | 13 | 15 |
| Nominal Output Voltage(V) | L/N/PE,220Vac,230Vac,240Vac | L/N/PE,220Vac,230Vac,240Vac | L/N/PE,220Vac,230Vac,240Vac | L/N/PE,220Vac,230Vac,240Vac | L/N/PE,220Vac,230Vac,240Vac |
| Grid Voltage Range | 180Vac-276Vac(According to local standard) | 180Vac-276Vac(According to local standard) | 180Vac-276Vac(According to local standard) | 180Vac-276Vac(According to local standard) | 180Vac-276Vac(According to local standard) |
| Nominal Output Frequency(Hz) | 50/60 | 50/60 | 50/60 | 50/60 | 50/60 |
| Grid Frequency Range | 45-55Hz/54-66Hz (According to local standard) | 45-55Hz/54-66Hz (According to local standard) | 45-55Hz/54-66Hz (According to local standard) | 45-55Hz/54-66Hz (According to local standard) | 45-55Hz/54-66Hz (According to local standard) |
| Output Power Factor | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) | 1 default (adjustable from 0.8 leading to 0.8 lagging) |
| Output Current THD | <3% | <3% | <3% | <3% | <3% |
| Efficiency | |||||
| Max.Efficiency | 97.50% | 97.80% | 98.10% | 98.10% | 98.13% |
| Euro Efficiency | 96.60% | 96.70% | 96.80% | 97.23% | 97.56% |
| Protection | |||||
| PV Reverse Polarity Protection | YES | YES | YES | YES | YES |
| PV Insulation Resistance Detection | YES | YES | YES | YES | YES |
| AC Short Circuit Protection | YES | YES | YES | YES | YES |
| AC Over Current Protection | YES | YES | YES | YES | YES |
| AC Over Voltage Protection | YES | YES | YES | YES | YES |
| Anti-Islanding Protection | YES | YES | YES | YES | YES |
| Residual Current Detection | YES | YES | YES | YES | YES |
| Over Temperature Protection | YES | YES | YES | YES | YES |
| Integrated DC switch | YES | YES | YES | YES | YES |
| Surge Protection | Integrated(Type Ill) | Integrated(Type Ill) | Integrated(Type Ill) | Integrated(Type Ill) | Integrated(Type Ill) |
| Smart IV Curve Scaning | YES | YES | YES | YES | YES |
| Quick Arc Fault Circuit interruption | Optional | Optional | Optional | Optional | Optional |
| General Data | |||||
| Dimensions (WxHxD,mm) | 280x260x116 | 280x260x116 | 280x260x116 | 280x260x116 | 280x260x116 |
| Weight(kg) | 6 | 6 | 6 | 6 | 6 |
| Protection Degree | IP65 | IP65 | IP65 | IP65 | IP65 |
| Enclosure Material | Aluminum | Aluminum | Aluminum | Aluminum | Aluminum |
| Ambient Temperature Range(℃) | -25 to 60 | -25 to 60 | -25 to 60 | -25 to 60 | -25 to 60 |
| Humidity Range | 0-100% | 0-100% | 0-100% | 0-100% | 0-100% |
| Topology | Transformerless | Transformerless | Transformerless | Transformerless | Transformerless |
| Communication Interface | RS485/WiFi/Wire Ethernet/GPRS(optional) | RS485/WiFi/Wire Ethernet/GPRS(optional) | RS485/WiFi/Wire Ethernet/GPRS(optional) | RS485/WiFi/Wire Ethernet/GPRS(optional) | RS485/WiFi/Wire Ethernet/GPRS(optional) |
| Cooling Concept | Convection | Convection | Convection | Convection | Convection |
| Night Power Consumption(W) | <0.2 | <0.2 | <1 | <1 | <1 |
| Max.Operation Altitude(m) | 4000 | 4000 | 4000 | 4000 | 4000 |
| Certifications and Standards | |||||
| EMC Standard | EN/IEC 61000-6-2,EN/IEC 61000-6-3,EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3,EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3,EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3,EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 | EN/IEC 61000-6-2,EN/IEC 61000-6-3,EN61000-3-2, EN61000-3-3, EN61000-3-11, EN61000-3-12 |
| Safety Standard | IEC 60068, UL1741, EN62109 | IEC 60068, UL1741, EN62109 | IEC 60068, UL1741, EN62109 | IEC 60068, UL1741, EN62109 | IEC 60068, UL1741, EN62109 |
| Grid-connection | IEEE1547,CSA C22,EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | IEEE1547,CSA C22,EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | IEEE1547,CSA C22,EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | IEEE1547,CSA C22,EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 | IEEE1547,CSA C22,EN50549, VDE4105, VDE0126, RD1699, ABNT NBR16149 & 16150, AS4777.2, NB/T32004, G98/G99, IEC61727 |
