Rozwiązanie ESS do szaf zewnętrznych
Opis

100% Unbalanced Output

150% Backup Overload

UPS Level Switch Time ≤ 10ms

Parallel Operation Extend to 300kW

Product introduction

Technical DataAF36K-ATHAF40K-ATHAF50K-ATH
PV Input
Max. DC Input Power (kW)546075
Max.PV Voltage(V)100010001000
Rated DC Input Voltage (V)620620620
DC Input Voltage Rang(V)150-1000150-1000150-1000
MPPT Voltage Range (V)150-850150-850150-850
Full MPPT Range(V)500-850500-850500-850
Start-up Voltage (V)160160160
Max.DC Input Current (A)40x440x440x4
Max.Short Current(A)48x448x448x4
No.of MPPT Tracker / Strings4/84/84/8
Battery Port
Battery Nominal Voltage(V)500500500
Battery Voltage Range (V)150-800150-800150-800
Max.Charge/Discharge Current(A)120120120
Max. Charge/Discharge Power (kW)364050
Charging Curve3 Stages3 Stages3 Stages
Compatible Battery TypeLi-ion/Lead-acid/Sodium metal chloride batteryLi-ion/Lead-acid/Sodium metal chloride batteryLi-ion/Lead-acid/Sodium metal chloride battery
AC Grid
Nominal AC Output Power (kW)364050
Max. AC Input/Output Power (kVA)72/39.680/44100/55
Max. AC Output Current(A)60.0666.7783.38
Nominal AC Voltage (V)230/400230/400230/400
Nominal AC Frenquency (Hz)50/6050/6050/60
Power Factor1(-0.8-0.8)1(-0.8-0.8)1(-0.8-0.8)
Current THD(%)<3%<3%<3%
AC Load Output (Back-up)
Nominal Output Power(VA)360004400055000
Nominal Output Voltage (V)230/400230/400230/400
Nominal Output Frequency (Hz)50/6050/6050/60
Nominal Output Current(A)52.25872.5
Peak Output Power54000VA, 10s / 39600VA, 60s60000VA,10s/44000VA,60s75000VA, 10s/ 55000VA, 60s
THDV (with linear load)3%3%3%
Switching Time(ms)<10<10<10
Efficiency
Europe Efficiency98.20%98.30%98.30%
Max. Efficiency98.60%98.60%98.60%
Battery Charge/Discharge Efficiency99.00%99.00%99.00%
Protection
Reverse Polarity ProtectionYesYesYes
Over Current/Voltage ProtectionYesYesYes
Anti-islanding ProtectionYesYesYes
AC Short-ciruit ProtectionYesYesYes
Leakage Current DetectionYesYesYes
Ground Fault MonitoringYesYesYes
Grid MonitoringYesYesYes
Enclosure Protect LevelIP66IP66IP66
AC/DC surge protectionType lIType lIType lI
General Data
Dimensions (WxHx D,mm)979x610x310mm979x610x310mm979x610x310mm
Weight (kg)70kg70kg70kg
TopologyTransformerlessTransformerlessTransformerless
Cooling ConceptIntelligent FanIntelligent FanIntelligent Fan
Relative Humidity0-100%0-100%0-100%
Operating Temperature Range (℃)-25 to 60℃-25 to 60℃-25 to 60℃
Operating Altitude (m)<4000<4000<4000
Standby Consumption (W)<100<100<100
Display & Communication InterfacesLCD,LED,RS485, CAN,Wi-Fi,GPRS,4GLCD,LED,RS485, CAN,Wi-Fi,GPRS,4GLCD,LED,RS485, CAN,Wi-Fi,GPRS,4G
Certification & ApprovalsNRS097,G98/G99,EN50549-1,C10/C11, AS4777.2 ,VDEAR-N4105 ,VDE0126, IEC62109-1, IEC621092NRS097,G98/G99,EN50549-1,C10/C11, AS4777.2 ,VDEAR-N4105 ,VDE0126, IEC62109-1, IEC621092NRS097,G98/G99,EN50549-1,C10/C11, AS4777.2 ,VDEAR-N4105 ,VDE0126, IEC62109-1, IEC621092
EMCEN61000-6-2, EN61000-6-3EN61000-6-2, EN61000-6-3EN61000-6-2, EN61000-6-3
Model AF100KW-LI
DC Data
Battery chemistryLiFePO4
Cycle life≥6000(@25℃,0.5C/0.5C)
Cell spec3.2V/100Ah
Battery module capacity10.24KWh
string configuration2P160S
Number of strings1
Rated energy capacity102.4KWh
Rated voltage512V
Voltage range448V-584V
General Data
Dimension (W*D*H)1100x1100x2380mm
Weight of the whole system<1.5T
Degree of protectionIP54
Cooling methodHVAC
Fire Fighting SystemHot aerosol fire extinguishing
Operating temperature range-20~40℃
Relative humidity0~95%(non-condensing)
Max working altitude≤3,000m(9,842ft)
Communication interfacesCAN
StandardsUN38.3
