Opis
Real-time Monitoring
Durability
Intelligent BMS
Seamless Integration
Product introduction
| Model | Low Voltage Stackable energy storage battery AF5000W-LE |
|---|---|
| Parameter | |
| Nominal Voltage(Vdc) | 51.2 |
| Nominal Capacity(Wh) | 5120 |
| Working Voltage Range(Vdc) | 44.8-56.16 |
| Charge Voltage(Vdc) | 58.4 |
| Nominal Charge/Discharge Current(A) | 50 |
| Max.Charge/Discharge Current(A) | 100 |
| Peak Current(A) | 200@3sec |
| Parallel Connection | ≤6 pcs |
| Cycle Life | 6000 @80% DOD,25℃/0.5C |
| Structure | |
| Dimension(mm) | 600*210*300 |
| Weight(kg) | 50.5 |
| IP Rating | IP65 |
| Installation | Stacked |
| Working Environment | |
| Charge Working Temperature(℃) | 0-55 |
| Discharge Working Temperature(℃) | -20~60 |
| Altitude(M) | <2500 |
| Humidity(RH) | 5-95%(w/o condensing) |
| Communication | |
| Communication Port | RS485, CAN |
| Display | SOC status indicator, LED indicator |
| Certification | |
| CB, IEC62619; CE-EMC, CE-GPSD, UKCA; UN38.3, MSDS |
