Inverter ibrido monofase 3-9,6kW

AF3-9.6K-DH

Download PDF >

 Contact US >

Inverter ibrido monofase 3-9,6kW
Descrizione

The Afore AF Series storage Inverters are designed to increase energy independence for homeowners. The power range is from 3.0kW to 9.6kW, compatible with high voltage (80-495V) batteries.

Support for Time-of-use Optimization

AFCl & Rapid Shutdown Ready

Build in Anti-feed-in Function

Smart Monitoring & Remote Firmware Upgrade

Product introduction

Technical DataAF3K-DHAF3.6K-DHAF4K-DHAF4.6K-DHAF5K-DHAF5.5K-DH
PV Input
Max.Input Power(kW)4.55.46.06.97.58.3
Max.PV Voltage(V)600600600600600600
MPPT Range (V)80-55080-55080-55080-55080-55080-550
Ful MPPT Range (V)110-550135-550150-550 170-550185-550200-550
l Normal Voltage (V)360360360360360360
Startup Voltage (V)100100100100100100
Max. Input Current (A)15.5x215.5x215.5x215.5x215.5x215.5x2
Max.Short Current(A)26.0x226.0x226.0x226.0x226.0x226.0x2
No.of MPP Tracker / No. of PV String2/22/22/22/22/22/2
Battery Port
Max. Charge/Discharge Power (kW)4.5/4.55.4/5.46.0/6.06.9/6.97.5/7.58.3/8.3
Max.Charge/Discharge Current (A)505050505050
Battery Normal Voltage (V)230230230230230230
Battery Voltage Range (V)80-49580-49580-49580-49580-49580-495
Battery TypeLi-ion/Lead-acidLi-ion/Lead-acidLi-ion/Lead-acidLi-ion/Lead-acidLi-ion/Lead-acidLi-ion/Lead-acid
AC Grid
Max Continuous Current (A)1517.519.522.524.527
Max Continuous Power (kVA)3.03.64.04.65.05.5
Nominal Grid Current(A)12.5/14.515.0/17.5 17.0/19.5 19.5/22.521.0/2423.0/26.5
Nominal Grid Voltage (V)211 to 264@240/183 to 229@208211 to 264@240/183 to 229@208211 to 264@240/183 to 229@208211 to 264@240/183 to 229@208211 to 264@240/183 to 229@208211 to 264@240/183 to 229@208
Nominal Grid Frequency (Hz)606060606060
Power Factor 1 default (adjustable from 0.8 leading to 0.8 lagging) 1 default (adjustable from 0.8 leading to 0.8 lagging) 1 default (adjustable from 0.8 leading to 0.8 lagging) 1 default (adjustable from 0.8 leading to 0.8 lagging) 1 default (adjustable from 0.8 leading to 0.8 lagging) 1 default (adjustable from 0.8 leading to 0.8 lagging)
Current THD (%)<3<3<3<3<3<3
Gen Input & AC Load Output
Max. Continuous Current (A)1517.519.522.524.527
Max. Continuous Power (kVA)3.03.64.04.65.05.5
Max. Peak Current (A) (10min)18.8/21.722.5/26 25/28.9 28.8/33.231.3/36.134.6/39.9
Max. Peak Power (kVA) (10min)4.5/4.55.4/5.46.0/6.0 6.9/6.97.5/7.58.3/8.3
Nominal AC Voltage L-L(V)240/208240/208240/208240/208240/208240/208
Nominal AC Voltage L-N (V)120/104120/104120/104120/104120/104120/104
Nominal AC Frequency (Hz)606060606060
Switching Time (ms)<10<10<10<10<10<10
Voltage THD (%)<3<3<3<3<3<3
Efficiency
CEC Efficiency(%)97.097.097.097.097.097.0
Max.Eficiency(%)97.697.697.697.697.697.6
PV to Bat. Efficiency (%)98.198.198.198.198.198.1
Bat. between AC Efficiency (%)96.896.896.896.896.896.8
Protection
PV Reverse Polarity ProtectionYesYesYesYesYesYes
Bat. Reverse Polarity ProtectionYesYesYesYesYesYes
Over Current/Voltage ProtectionYesYesYesYesYesYes
Anti-Islanding ProtectionYesYesYesYesYesYes
AC Short Circuit ProtectionYesYesYesYesYesYes
Residual Current DetectionYesYesYesYesYesYes
Ground Fault MonitoringYesYesYesYesYesYes
Insulation Resister DetectionYesYesYesYesYesYes
PV Arc DetectionYesYesYesYesYesYes
Rapid Shut DownYesYesYesYesYesYes
Protection DegreeIP65 / NEMA4XIP65 / NEMA4XIP65 / NEMA4XIP65 / NEMA4XIP65 / NEMA4XIP65 / NEMA4X
AC/DC surge protectionType llType llType llType llType llType ll
General Data
Dimensions (Wx HxD)400x600x229 mm/15.7x 23.6x 9.0 in400x600x229 mm/15.7x 23.6x 9.0 in400x600x229 mm/15.7x 23.6x 9.0 in400x600x229 mm/15.7x 23.6x 9.0 in400x600x229 mm/15.7x 23.6x 9.0 in400x600x229 mm/15.7x 23.6x 9.0 in
Weight25 kg/55 lbs25 kg/55 lbs25 kg/55 lbs25 kg/55 lbs25 kg/55 lbs25 kg/55 lbs
TopologyTranformerlessTranformerlessTranformerlessTranformerlessTranformerlessTranformerless
CoolingNatural ConvectionNatural ConvectionNatural ConvectionNatural ConvectionNatural ConvectionNatural Convection
Relative Humidity0-100%0-100%0-100%0-100%0-100%0-100%
Operating Temperature Range-25 to 60℃ / - 77 to 140 °℉-25 to 60℃ / - 77 to 140 °℉-25 to 60℃ / - 77 to 140 °℉-25 to 60℃ / - 77 to 140 °℉-25 to 60℃ / - 77 to 140 °℉-25 to 60℃ / - 77 to 140 °℉
Operating Altitude<4000 m><4000 m><4000 m><4000 m><4000 m><4000 m>
Standby Consumption (W)<10<10<10<10<10<10
MountingWall BracketWall BracketWall BracketWall BracketWall BracketWall Bracket
Communication with RSDSUNSPECSUNSPECSUNSPECSUNSPECSUNSPECSUNSPEC
Display & Communication InterfacesLCD,LED, RS485, CAN, Wi-Fi, 4GLCD,LED, RS485, CAN, Wi-Fi, 4GLCD,LED, RS485, CAN, Wi-Fi, 4GLCD,LED, RS485, CAN, Wi-Fi, 4GLCD,LED, RS485, CAN, Wi-Fi, 4GLCD,LED, RS485, CAN, Wi-Fi, 4G
Certification & Approvals UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14 UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14 UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14 UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14 UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14 UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14
EMCFCC part15 CLASS BFCC part15 CLASS BFCC part15 CLASS BFCC part15 CLASS BFCC part15 CLASS BFCC part15 CLASS B
Technical Data AF6K-DHAF7K-DHAF7.6K-DHAF8K-DH AF8.6K-DHAF9.6K-DH
PV Input
Max.Input Power(kW)9.010.511.41212.915.0
Max.PV Voltage (V)600600600600600600
MPPT Range (V)80-55080-55080-55080-55080-55080-550
Ful MPPT Range(V)220-550170-550185-550 195-550210-550235-550
l Normal Voltage (V)360360360360360360
Startup Voltage (V)100100100100100100
Max. Input Current (A)15.5x215.5x315.5x315.5x315.5x315.5x3
Max.Short Current (A)26.0x226.0x326.0x326.0x326.0x326.0x3
No.of MPP Tracker / No. of PV String2/2/3/3/3/3/3/3/3/3/3/3
Battery Port
Max. Charge/Discharge Power (kW)9.0/9.010.5/10.311.4/10.3 11.5/10.311.5/10.311.5/10.3
Max. Charge/Discharge Current (A)505050505050
Battery Normal Voltage (V)230230230230230230
Battery Voltage Range (V)80-49580-49580-49580-49580-49580-495
Battery TypeLi-ion/Lead-acidLi-ion/Lead-acidLi-ion/Lead-acidLi-ion/Lead-acidLi-ion/Lead-acidLi-ion/Lead-acid
AC Grid
Max Continuous Current (A)29.034.0373941.546.5
Max Continuous Power (kVA)6.07.07.688.69.6
Nominal Grid Current (A)25.0/29.029.5/34.032.0/36.5 33.5/38.536.0/41.540.0/46.5
Nominal Grid Voltage (V)211 to 264@240/183 to 229@208211 to 264@240/183 to 229@208211 to 264@240/183 to 229@208211 to 264@240/183 to 229@208211 to 264@240/183 to 229@208211 to 264@240/183 to 229@208
Nominal Grid Frequency (Hz)606060606060
Power Factor1 default (adjustable from 0.8 leading to 0.8 lagging)1 default (adjustable from 0.8 leading to 0.8 lagging)1 default (adjustable from 0.8 leading to 0.8 lagging)1 default (adjustable from 0.8 leading to 0.8 lagging)1 default (adjustable from 0.8 leading to 0.8 lagging)1 default (adjustable from 0.8 leading to 0.8 lagging)
Current THD (%)<3<3<3<3<3<3
Gen Input & AC Load Output
Max. Continuous Current (A)29.034.0373941.546.5
Max Continuous Power (kVA)6.07.07.688.69.6
. Max. Peak Current (A) (10min)37.5/43.343.8/49.547.5/49.5 47.9/49.547.9/49.547.9/49.5
Max.Peak Power(kVA)(10min)9.0/9.010.5/10.311.4/10.311.5/10.311.5/10.311.5/10.3
Nominal AC Voltage L-L(V)240/208240/208240/208240/208240/208240/208
Nominal AC Voltage L-N (V)120/ 104120/ 104120/ 104120/ 104120/ 104120/ 104
Nominal AC Frequency (Hz)606060606060
Switching Time(ms)<10<10<10<10<10<10
Voltage THD (%)<3<3<3<3<3<3
Efficiency
CEC Efficiency (%)97.097.097.097.097.097.0
Max.Efficiency(%)97.697.697.697.697.697.6
PV to Bat. Efficiency (%)98.198.198.198.198.198.1
Bat.between AC Efficiency (%)96.896.896.896.896.896.8
Protection
PV Reverse Polarity ProtectionYesYesYesYesYesYes
Bat. Reverse Polarity ProtectionYesYesYesYesYesYes
Over Current/Voltage ProtectionYesYesYesYesYesYes
Anti-Islanding ProtectionYesYesYesYesYesYes
AC Short Circuit ProtectionYesYesYesYesYesYes
Residual Current DetectionYesYesYesYesYesYes
Ground Fault MonitoringYesYesYesYesYesYes
Insulation Resister DetectionYesYesYesYesYesYes
PV Arc DetectionYesYesYesYesYesYes
Rapid Shut DownYesYesYesYesYesYes
Protection DegreeIP65 / NEMA4XIP65 / NEMA4XIP65 / NEMA4XIP65 / NEMA4XIP65 / NEMA4XIP65 / NEMA4X
AC/DC surge protectionType IIType IIType IIType IIType IIType II
General Data
Dimensions (Wx Hx D)400x600x229mm/15.7x23.6x9.0 in400x600x229mm/15.7x23.6x9.0 in400x600x229mm/15.7x23.6x9.0 in400x600x229mm/15.7x23.6x9.0 in400x600x229mm/15.7x23.6x9.0 in400x600x229mm/15.7x23.6x9.0 in
Weight25 kg/55 lbs25 kg/55 lbs25 kg/55 lbs25 kg/55 lbs25 kg/55 lbs25 kg/55 lbs
TopologyTranformerlessTranformerlessTranformerlessTranformerlessTranformerlessTranformerless
CoolingNatural ConvectionIntelligent FanIntelligent FanIntelligent FanIntelligent FanIntelligent Fan
Relative Humidity0-100%0-100%0-100%0-100%0-100%0-100%
Operating Temperature Range-25 to 60℃ / - 77 to 140°℉-25 to 60℃ / - 77 to 140°℉-25 to 60℃ / - 77 to 140°℉-25 to 60℃ / - 77 to 140°℉-25 to 60℃ / - 77 to 140°℉-25 to 60℃ / - 77 to 140°℉
Operating Altitude<4000 m><4000 m><4000 m><4000 m><4000 m><4000 m>
Standby Consumption (W)<10<10<10<10<10<10
MountingWall BracketWall BracketWall BracketWall BracketWall BracketWall Bracket
Communication with RSDSUNSPECSUNSPECSUNSPECSUNSPECSUNSPECSUNSPEC
Display & Communication InterfacesLCD, LED, RS485, CAN, Wi-Fi, 4GLCD, LED, RS485, CAN, Wi-Fi, 4GLCD, LED, RS485, CAN, Wi-Fi, 4GLCD, LED, RS485, CAN, Wi-Fi, 4GLCD, LED, RS485, CAN, Wi-Fi, 4GLCD, LED, RS485, CAN, Wi-Fi, 4G
Certification & Approvals UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14 UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14 UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14 UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14 UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14 UL 1741 SA, UL 1741, UL1699B,UL 1998, IEEE1547, IEEE1547A, IEEE1547.1, CSA 22.2 No.107, Rule21, HECO Rule 14
EMCFCC part15 CLASS BFCC part15 CLASS BFCC part15 CLASS BFCC part15 CLASS BFCC part15 CLASS BFCC part15 CLASS B
